1/8"-1/2" OD 0.025"-0.083" WT SS Hydraulic Control Line Tubing Cold Drawn
We have been supplying our customers with the control line tubing with a customized length. Our materials are Austenitic steel 304L (UNS S30403), Austenitic steel 316L (UNS S31603), Duplex 2205 (UNS S32205 & S31803), Super Duplex 2507 (UNS S32750) , Incoloy 825 (UNS N08825), Inconel 625 (UNS N06625). And we can make wall thickness 0.025 "-0.083" and outer diameter 1/8 "-1/2". In addition, our control line tubing can be used under the working pressure of 60-120 Mpa.
Size Chart
| OD | Wall
(inch) | Materials | Standard | Working Pressure
(MPa) | Length |
| 1/8" | 0.02,0.028,0.035 | Austenitic steel 304L (UNS S30403)
Austenitic steel 316L (UNS S31603)
Duplex 2205 (UNS S32205 & S31803)
Super Duplex 2507 (UNS S32750)
Incoloy 825 (UNS N08825)
Inconel 625 (UNS N06625) | ASTM-A 269
ASTM-A 632
ASTM-A 789
ASTM-B 704 | 60-120 Mpa | Customized |
| 3/16" | 0.02,0.028,0.035,0.049 |
| 1/4" | 0.02,0.028,0.035,0.049,0.065.0.083 |
| 5/16" |
| 3/8" |
| 1/2" |
| OD: Up to 1 Inch The specification and length per coil can be customized according to customer’s requirements. |
We boast our excellent quality and competitive prices. Our foreign clients have been being very satisfied with our products. We are ready to establish long-term, reliable and mutually beneficial business relationship with our customers who need our services.
Chemical Composition
| Composition (%) |
| Standard | ASTM A269 | ASTM A789 | ASTM B704 |
| Material | SS 304 | SS 304L | SS 316 | SS 316L | Duplex 2205 | Super Duplex 2507 | Incoloy 625 | Incoloy 825 |
| UNS | S30400 | S30403 | S31600 | S31603 | S32205 | S32750 | N06625 | N08825 |
| C | 0.080 | 0.035 | 0.080 | 0.035 | 0.030 | 0.030 | 0.10 | 0.05 |
| Mn | 2.00 | 2.00 | 2.00 | 2.00 | 2.00 | 1.20 | 0.50 | 1.00 |
| P | 0.045 | 0.045 | 0.045 | 0.045 | 0.030 | 0.035 | 0.015 | ... |
| S | 0.030 | 0.030 | 0.030 | 0.030 | 0.020 | 0.020 | 0.015 | 0.030 |
| Si | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 0.80 | 0.50 | 0.50 |
| Ni | 8.0-11.0 | 8.0-12.0 | 10.0-14.0 | 10.0-15.0 | 4.5-6.5 | 6.0-8.0 | min 58.0 | 38.0-46.0 |
| Cr | 18.0-20.0 | 18.0-20.0 | 16.0-18.0 | 16.0-18.0 | 22.0-23.0 | 24.0-26.0 | 20.0-23.0 | 19.5-23.5 |
| Mo | ... | ... | 2.00-3.00 | 2.00-3.00 | 3.0-3.5 | 3.0-3.5 | 8.0-10.0 | 2.5-3.5 |
| N | ... | ... | ... | ... | 0.14-0.20 | 0.24-0.32 | ... | ... |
| Cu | ... | ... | ... | ... | ... | 0.50 | ... | 1.5-3.0 |
| Fe | ... | ... | ... | ... | ... | ... | 5.0 | min 22.0 |
| Al | ... | ... | ... | ... | ... | ... | 0.4 | 0.2 |
| Ti | ... | ... | ... | ... | ... | ... | 0.40 | 0.6-1.2 |
| Cb+Ta | ... | ... | ... | ... | ... | ... | 3.15-4.15 | ... |
FAQ
Q1: Can you arrange the shipment?
A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.
Q2: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 25-45 days if the goods are not in stock, it is according to quantity.
Q3. Can you provide customize service?
A: Yes.Pipes can be customized as per the customers' request.
Q4. How to ensure the quality?
A:Mill Test Certificate is supplied with shipment.
If needed, a Third Party Inspection is acceptable.
Product Tags:
|
|
Cold Drawn 1/2" OD SS Hydraulic Control Line Tubing Images
|
